Documentation

Overview

VoyagerOTA provides a simple yet powerful way to manage firmware updates for ESP32 and ESP8266 devices. The library is designed to be flexible, allowing you to use either the Voyager Platform backend or integrate with your own custom backend solution.

Features

• Header-only Design - Simple integration without complex build configurations
• Remote Updates - Firmware updates via HTTP with progress tracking
• Version Comparison - Built-in semantic version comparison
• Fully Customizable - Custom JSON parser and backend support
• HTTP Headers - Custom authentication and header configuration
• Environment Modes - STAGING/PRODUCTION support for Voyager Platform

Requirements

Quick Start

#include <VoyagerOTA.hpp>

void setup() {
    Serial.begin(115200);

    // Create OTA instance with current firmware version
    Voyager::OTA<> ota("1.0.0");

    // Set environment to PRODUCTION (defaults to STAGING)
    ota.setEnvironment(Voyager::PRODUCTION);

    // Fetch latest release information
    auto release = ota.fetchLatestRelease();

    if (release && ota.isNewVersion(release->version)) {
        Serial.println("New version available: " + release->version);
        Serial.println("Changelog: " + release->changeLog);

        // Perform the update
        ota.performUpdate();
    } else {
        Serial.println("No update available");
    }
}

void loop() {
    // Your main code here
}

Two Endpoints Approach

VoyagerOTA uses a Two Endpoints Approach for maximum flexibility:

Benefits

• Use different authentication methods for metadata vs. downloads
• Implement custom logic for release selection
• Support various backend architectures (CDN, database-driven, etc.)
• Parse different JSON response formats

Environment Settings

// Set environment (only applies to Voyager Platform)
ota.setEnvironment(Voyager::PRODUCTION);  // or Voyager::STAGING (default)

• STAGING - For testing and validation before release
• PRODUCTION - For production device distribution

Testing is performed by running production-ready firmware on devices configured to use the STAGING environment.

Default JSON Response Format

The Voyager Platform returns firmware metadata in this format:

{
  "release": {
    "id": "jJGoFvZ1Wxsb171NPQ2HL",
    "status": "staging",
    "version": "2.0.1",
    "changeLog": "Smart Lock Firmware",
    "releasedAt": null,
    "artifact": {
      "size": 1706512,
      "hash": "cbf34fe7537e1977b127eef7a207358a8a56980b14d903f998697cbdbe4e94f4",
      "downloadURL": "https://api.voyagerota.com/v1/releases/jJGoFvZ1Wxsb171NPQ2HL/downloads/UwkEyt7L_nUjXvqktor5l"
    }
  },
  "status": {
    "reason": "OK",
    "code": 200
  }
}

Default Payload Structure

The default DefaultPayloadModel includes:

• version - Firmware version string (required for comparisons)
• changeLog - Release notes
• releasedDate - Release date
• fileSize - Human readable file size
• fileSizeInBytes - File size in bytes
• boardType - Target board type
• environment - Release environment
• message - Status message
• statusCode - HTTP response code

Custom Backend Implementation

Backend Requirements

For the Two Endpoints Approach, your backend must implement:

Example minimal backend response:

{
    "version": "2.0.0"
}

Custom JSON Parser

Create your own parser for different JSON response formats:

#include <VoyagerOTA.hpp>

// Define your custom payload structure
struct CustomPayload {
    String version;        // Required for version comparison
    String description;
    String downloadUrl;
    int statusCode;
};

// Implement custom parser
class CustomParser : public Voyager::IParser<Voyager::ResponseData, CustomPayload> {
public:
    std::optional<CustomPayload> parse(Voyager::ResponseData responseData, int statusCode) override {
        ArduinoJson::JsonDocument doc;
        ArduinoJson::DeserializationError error = ArduinoJson::deserializeJson(doc, responseData);

        if (error) {
            Serial.println("JSON parsing failed");
            return std::nullopt;
        }

        if (statusCode != HTTP_CODE_OK) {
            CustomPayload payload = {
                .version = "0.0.0",
                .statusCode = statusCode
            };
            return payload;
        }

        CustomPayload payload = {
            .version = doc["version"].as<String>(),
            .description = doc["description"].as<String>(),
            .downloadUrl = doc["download_url"].as<String>(),
            .statusCode = statusCode
        };

        return payload;
    }
};

Configuration Methods

Header Configuration

// Option 1: Endpoint-specific headers
std::vector<Voyager::OTA<>::Header> releaseHeaders = {
    {"Authorization", "Bearer your-token"},
    {"Content-Type", "application/json"}
};
ota.setReleaseURL("https://api.example.com/releases", releaseHeaders);

std::vector<Voyager::OTA<>::Header> downloadHeaders = {
    {"Authorization", "Bearer your-token"},
    {"Accept", "application/octet-stream"}
};
ota.setDownloadURL("https://api.example.com/download", downloadHeaders);

// Option 2: Global headers for both endpoints
std::vector<Voyager::OTA<>::Header> globalHeaders = {
    {"User-Agent", "VoyagerOTA/1.0.0"},
    {"Authorization", "Bearer your-token"}
};
ota.setGlobalHeaders(globalHeaders);
ota.setReleaseURL("https://api.example.com/releases");
ota.setDownloadURL("https://api.example.com/download");

GitHub Releases Example

Here's a complete example of integrating VoyagerOTA with GitHub releases:

#include <VoyagerOTA.hpp>

// Define GitHub release payload structure
struct GithubReleaseModel {
    String version;           // Required for version comparison
    String name;
    String publishedAt;
    String browserDownloadUrl;
    int size;
    int statusCode;
};

// Implement GitHub JSON parser
class GithubJSONParser : public Voyager::IParser<Voyager::ResponseData, GithubReleaseModel> {
public:
    std::optional<GithubReleaseModel> parse(Voyager::ResponseData responseData, int statusCode) override {
        ArduinoJson::JsonDocument document;
        ArduinoJson::DeserializationError error = ArduinoJson::deserializeJson(document, responseData);

        if (error) {
            Serial.printf("VoyagerOTA JSON Error : %s\n", error.c_str());
            return std::nullopt;
        }

        if (statusCode != HTTP_CODE_OK) {
            GithubReleaseModel payload = {
                .version = "0.0.0",
                .statusCode = statusCode,
            };
            return payload;
        }

        GithubReleaseModel payload = {
            .version = document["tag_name"].template as<String>(),
            .name = document["name"].template as<String>(),
            .publishedAt = document["published_at"].template as<String>(),
            .browserDownloadUrl = document["assets"][0]["url"].template as<String>(),
            .size = document["assets"][0]["size"].template as<int>(),
            .statusCode = statusCode
        };

        return payload;
    }
};

void setup() {
    Serial.begin(115200);

    std::unique_ptr<GithubJSONParser> parser = std::make_unique<GithubJSONParser>();
    Voyager::OTA<Voyager::ResponseData, GithubReleaseModel> ota(std::move(parser), "2.0.0");

    ota.setReleaseURL("https://api.github.com/repos/owner/repo/releases/latest",
                      {
                          {"Authorization", "Bearer your-github-token"},
                          {"X-GitHub-Api-Version", "2022-11-28"},
                          {"Accept", "application/vnd.github+json"},
                      });

    Serial.println("OTA Engine Started!");

    std::optional<GithubReleaseModel> release = ota.fetchLatestRelease();

    if (release && ota.isNewVersion(release->version)) {
        Serial.println("New version available: " + release->version);
        Serial.println("Release name: " + release->name);

        ota.setDownloadURL(release->browserDownloadUrl,
                            {
                                {"Authorization", "Bearer your-github-token"},
                                {"X-GitHub-Api-Version", "2022-11-28"},
                                {"Accept", "application/octet-stream"},
                            });

        ota.performUpdate();
    } else {
        Serial.println("No updates available yet!");
    }
}

void loop() {}

Version Management

// Set current firmware version
ota.setCurrentVersion("2.1.0");

// Get current version
String current = ota.getCurrentVersion();

// Check if a version is newer
bool hasUpdate = ota.isNewVersion("2.2.0");

Error Handling

The library provides some error handling and logging:

• JSON parsing errors are logged to Serial with detailed error messages
• HTTP errors are captured in the payload's statusCode field
• Update progress and errors are reported through Serial output

License

MIT License - see the source file header for complete license text.
